Lock nuts with locking washer
Datasheet
| Lock Nuts | Appropriate Locking Washer | G | d1 | d3 | B | b | h | Weight |
| – | - | mm | mm | mm | mm | mm | mm | kg |
| KM 0 | MB 0 | M 10x0,75 | 13,5 | 18 | 4 | 3 | 2 | 0,004 |
| KM 1 | MB 1 | M 12x1 | 17 | 22 | 4 | 3 | 2 | 0,006 |
| KM 2 | MB 2 | M 15x1 | 21 | 25 | 5 | 4 | 2 | 0,009 |
| KM 3 | MB 3 | M 17x1 | 24 | 28 | 5 | 4 | 2 | 0,012 |
| KM 4 | MB 4 | M 20x1 | 26 | 32 | 6 | 4 | 2 | 0,025 |
| KM 5 | MB 5 | M 25x1,5 | 32 | 38 | 7 | 5 | 2 | 0,028 |
| KM 6 | MB 6 | M 30x1,5 | 38 | 45 | 7 | 5 | 2 | 0,039 |
| KM 7 | MB 7 | M 35x1,5 | 44 | 52 | 8 | 5 | 2 | 0,059 |
| KM 8 | MB 8 | M 40x1,5 | 50 | 58 | 9 | 6 | 2,5 | 0,078 |
| KM 9 | MB 9 | M 45x1,5 | 56 | 65 | 10 | 6 | 2,5 | 0,11 |
| KM 10 | MB 10 | M 50x1,5 | 61 | 70 | 11 | 6 | 2,5 | 0,14 |
| KM 11 | MB 11 | M 55x2 | 67 | 75 | 11 | 7 | 3 | 0,15 |
| KM 12 | MB 12 | M 60x2 | 73 | 80 | 11 | 7 | 3 | 0,16 |
| KM 13 | MB 13 | M 65x2 | 79 | 85 | 12 | 7 | 3 | 0,19 |
| KM 14 | MB 14 | M 70x2 | 85 | 92 | 12 | 8 | 3,5 | 0,23 |
| KM 15 | MB 15 | M 75x2 | 90 | 98 | 13 | 8 | 3,5 | 0,27 |
| KM 16 | MB 16 | M 80x2 | 95 | 105 | 15 | 8 | 3,5 | 0,36 |
| KM 17 | MB 17 | M 85x2 | 102 | 110 | 16 | 8 | 3,5 | 0,41 |
| KM 18 | MB 18 | M 90x2 | 108 | 120 | 16 | 10 | 4 | 0,51 |
| KM 19 | MB 19 | M 95x2 | 113 | 125 | 17 | 10 | 4 | 0,55 |
| KM 20 | MB 20 | M 100x2 | 120 | 130 | 18 | 10 | 4 | 0,64 |
| KM 21 | MB 21 | M 105x2 | 126 | 140 | 18 | 12 | 5 | 0,79 |
| KM 22 | MB 22 | M 110x2 | 133 | 145 | 19 | 12 | 5 | 0,87 |
| KM 23 | MB 23 | M 115x2 | 137 | 150 | 19 | 12 | 5 | 0,91 |
| KML 24 | MBL 24 | M 120x2 | 135 | 145 | 20 | 12 | 5 | 0,69 |
| KM 24 | MB 24 | M 120x2 | 138 | 155 | 20 | 12 | 5 | 0,97 |
| KM 25 | MB 25 | M 125x2 | 148 | 160 | 21 | 12 | 5 | 1,09 |
| KML 26 | MBL 26 | M 130x2 | 145 | 155 | 21 | 12 | 5 | 0,80 |
| KM 26 | MB 26 | M 130x2 | 149 | 165 | 21 | 12 | 5 | 1,09 |
| KM 27 | MB 27 | M 135x2 | 160 | 175 | 22 | 14 | 6 | 1,39 |
| KML 28 | MBL 28 | M 140x2 | 155 | 165 | 22 | 12 | 5 | 0,92 |
| KM 28 | MB 28 | M 140x2 | 160 | 180 | 22 | 14 | 6 | 1,40 |
| KM 29 | MB 29 | M 145x2 | 171 | 190 | 24 | 14 | 6 | 1,80 |
| KML 30 | MBL 30 | M 150x2 | 170 | 180 | 24 | 14 | 5 | 1,25 |
| KM 30 | MB 30 | M 150x2 | 171 | 195 | 24 | 14 | 6 | 1,88 |
| KM 31 | MB 31 | M 155x3 | 182 | 200 | 25 | 16 | 7 | 2,09 |
| KML 32 | MBL 32 | M 160x3 | 180 | 190 | 25 | 14 | 5 | 1,39 |
| KM 32 | MB 32 | M 160x3 | 182 | 210 | 25 | 16 | 7 | 2,29 |
| KM 33 | MB 33 | M 165x3 | 193 | 210 | 26 | 16 | 7 | 2,31 |
| KML 34 | MBL 34 | M 170x3 | 190 | 200 | 26 | 16 | 5 | 1,56 |
| KM 34 | MB 34 | M 170x3 | 193 | 220 | 26 | 16 | 7 | 2,34 |
| KML 36 | MBL 36 | M 180x3 | 200 | 210 | 27 | 16 | 5 | 1,78 |
| KM 36 | MB 36 | M 180x3 | 203 | 230 | 27 | 18 | 8 | 2,78 |
| KML 38 | MBL 38 | M 190x3 | 210 | 220 | 28 | 16 | 5 | 1,84 |
| KM 38 | MB 38 | M 190x3 | 214 | 240 | 28 | 18 | 8 | 3,05 |
| KML 40 | MBL 40 | M 200x3 | 222 | 240 | 29 | 18 | 8 | 2,61 |
| KM 40 | MB 40 | M 200x3 | 226 | 250 | 29 | 18 | 8 | 3,37 |
